In stock · Ready to ship Peplink MAX BR1 Pro 5G Cellular Router (FirstNet Capable, T-Priority)
Cellular Routers

Peplink MAX BR1 Pro 5G Cellular Router (FirstNet Capable, T-Priority)

Pricing on sign-up

Pricing for Peplink MAX BR1 Pro 5G Cellular Router (FirstNet Capable, T-Priority) is available to Paygasus customers.

Create a free account to unlock pricing, configure connectivity, and add this device to your cart. Takes under a minute — no payment details required.

Sign up to unlock pricing Talk to sales
T-Priority FirstNet Built with AT&T Verizon Frontline AT&T

High-performance industrial 5G router with PoE input capability. Features multi-core CPU, Wi-Fi 6, 2.5Gbps WAN, and full SpeedFusion for demanding mobile applications.

SKU: MAX-BR1-PRO-5GK-T-PRM
Pairs with

Complete your build with compatible devices

View available accessories
0 selected · $0.00
Overview

Curbside equipment rarely has a spare outlet. EV chargers, parking pay stations, pole-mounted cameras and traffic signal cabinets need connectivity where power is limited and a technician visit is expensive.

The Peplink MAX BR1 Pro 5G combines one 5G modem with dual SIM slots, a 2.5G Ethernet WAN, two gigabit LAN ports and dual-band Wi-Fi 6. It accepts 802.3at PoE input, so one cable carries both power and data, and it also runs from 10V to 30V DC or an AC adapter.

The metal enclosure is rated -40 to 65 °C with surge and ESD protection on the ports. The router is certified for AT&T, T-Mobile, Verizon and FirstNet, includes GPS, and provides 8GB of storage for Docker applications at the edge.

Product details
In the box
  • 1x BR1 Pro 5G
  • 4x LTE/5G Antennas (ACW-235)
  • 2x Dual Band Wi-Fi Antennas (ACW-341)
  • 1x GPS Active Antenna (ACW-232)
  • 1x 12V 2A 4 Pin Power Supply (ACW-632)
Built for
EV charging stationsParking pay stationsPole-mounted camera & sensor sitesTraffic signal cabinetsDigital signage & wayfinding
Specifications
Enclosure
Indoor, Metal
WAN Interface
1x 2.5G Ethernet (convertible to LAN), 1x Embedded 5G Modem with 2 SIM slots
LAN Interface
2x 10/100/1000M Ethernet (3 when the WAN port is set to LAN)
Recommended Users
1-150
SIM Options
2x Nano-SIM (4FF), Peplink eSIM, BYO eSIM, RemoteSIM from SIM Injector (HW2+), FusionSIM (HW2+)
Antenna Connectors
4x SMA Cellular Connectors
Power Input
AC adapter: 100V-240V input / 12V 2A output; DC: 10V-30V; K/PoE model (HW3) adds 802.3at PoE input on a LAN port
Power Consumption
8W (nominal) / 19W (max.)
Weight
K/PoE model (HW3): 720 g / 1.59 lb; earlier hardware (HW1-2): 680 g / 1.50 lb
Humidity
15%-95% (non-condensing)
Certifications
FCC, CE, RoHS, E-Mark, EN 61373 Shock and Vibration, EN 50155 Railway Rolling Stock, EN 61000 EMC, EN 45545-2 Railway Fire Protection, MIL-STD-810H Method 514.8 (TAA Compliant per cover)
Package Content
1x MAX BR1 Pro 5G; 1x 12V 2A power supply; 4x LTE/5G antennas; 2x Wi-Fi antennas; 1x GPS antenna
Warranty
1-Year Limited Warranty
SpeedFusion Features
Hot Failover, Smoothing, Bandwidth Bonding
Router Throughput
1 Gbps
Dimensions
K/PoE model (HW3): 5.78 x 5.68 x 1.15 in / 146.8 x 144.3 x 29.3 mm; earlier hardware (HW1-2): 5.78 x 5.08 x 1.15 in / 146.8 x 129 x 29.3 mm
Wi-Fi Interface
Dual-band (2.4GHz / 5GHz) Wi-Fi 6, 2x2 MIMO, 16 SSIDs, Wi-Fi WAN and/or AP
AP Controller
Yes (max. 30 APs / 50 switches)
Edge Computing
K/PoE model (HW3): Docker with 8GB onboard storage; earlier hardware (HW1-2): not supported
Cellular Antenna Connectors
4x SMA
GPS Antenna Connector
Yes
Maximum Number of APs Supported
30
PepVPN Throughput (No Encryption)
400 Mbps
PepVPN Throughput (256-bit AES)
200 Mbps
Cellular 1 Data Rate (Downlink/Uplink)
5G: 4.1 Gbps / 900 Mbps; CAT-20: 2 Gbps / 211 Mbps (maximum theoretical rates)
Number of PepVPN / SpeedFusion Peers
2 / 5 / 10 or 20 (default / PrimeCare / license)
802.1q VLANs Supported
16
Drop-In Mode
Yes
High Availability
Yes
Number of IPsec Tunnels
5
PoE Output
No
Operating Temperature
-40 to 149 F / -40 to 65 C
Compatibility
AT&T, T-Mobile, Verizon, FirstNet. T-Priority: 5GN and 5GK models
Serial
No
Recommended PPTP/L2TP/OpenVPN Users
3
Cellular WAN Interface
1x Embedded 5G Modem with 2 SIM slots
