In stock · Ready to ship Peplink MAX Transit Duo Pro Dual LTE-A Cellular Router (FirstNet Capable)
Cellular Routers

Peplink MAX Transit Duo Pro Dual LTE-A Cellular Router (FirstNet Capable)

Pricing on sign-up

Pricing for Peplink MAX Transit Duo Pro Dual LTE-A Cellular Router (FirstNet Capable) is available to Paygasus customers.

Create a free account to unlock pricing, configure connectivity, and add this device to your cart. Takes under a minute — no payment details required.

Sign up to unlock pricing Talk to sales
T-Priority FirstNet Built with AT&T Verizon Frontline AT&T

Dual LTE-A CAT-12 vehicle router with Wi-Fi 6, GPS and a full antenna set, certified for AT&T, T-Mobile, Verizon and FirstNet.

SKU: MAX-TST-PRO-DUO-LTEA-Q-T-PRM
Pairs with

Complete your build with compatible devices

View available accessories
0 selected · $0.00
Overview

Transit buses, work trucks and response vehicles move through coverage gaps that no single carrier fills, and the equipment on board needs Wi-Fi and a stable connection the whole route.

The Peplink MAX Transit Duo Pro carries two LTE-A CAT-12 modems with four nano-SIM slots, one gigabit Ethernet port usable as WAN or LAN, dual-band Wi-Fi 6 and GPS. Routing is 1 Gbps with 400 Mbps of SpeedFusion for 25 to 150 users, and 8GB of storage supports edge applications.

It runs from 12V to 56V DC or USB-C, rated -40 to 65 °C in a 730-gram metal chassis, and is certified for AT&T, T-Mobile, Verizon and FirstNet.

Product details
In the box
  • MAX Transit Duo Pro
  • 4x LTE Antennas (ACW-234)
  • 2x Wi-Fi Dual Band Antenna (ACW-341)
  • 1x GPS Active Antenna (ACW-232)
  • 1x 12V 2A 4 Pin Power Supply (ACW-632)
  • 6 Pin Terminal Block Connector
  • Mounting Brackets (ACW-724)
Built for
Municipal bus fleetsPublic works dump and plow trucksAnimal control and code enforcement vehiclesAirport shuttle fleetsCounty sheriff patrol vehicles
Specifications
Enclosure
Indoor, Metal
WAN Interface
1x 10/100/1000M Ethernet (configurable as WAN); max config: 1 WAN with 1 LAN, 0 WAN with 2 LAN
LAN Interface
1x 10/100/1000M Ethernet (configurable as LAN; 1 / 2 GE LAN)
Recommended Users
25–150
SIM Options
4 SIM slots, Nano-SIM; RemoteSIM: Yes; FusionSIM: Yes; Peplink eSIM Data Plans and BYO eSIM supported
Antenna Connectors
4x SMA Cellular Connectors
Power Input
12V–56V DC (power port); AC adapter: 100V–240V AC input, 12V 2A DC output; 2x USB-C 20V, 3A each
Power Consumption
10W (nominal), 18W (max.)
Weight
1.61 pounds / 730 grams
Humidity
15%–95% (non-condensing)
Certifications
FCC, CE, RoHS, IC; E-Mark; EN 61373 Shock and Vibration Resistance; EN 50155 Railway Applications; EN 61000 Electromagnetic Compatibility
Package Content
MAX Transit Duo Pro 4x LTE Antennas (ACW-234) 2x Wi-Fi Dual Band Antenna (ACW-341) 1x GPS Active Antenna (ACW-232) 1x 12V 2A 4 Pin Power Supply (ACW-632) 6 Pin Terminal Block Connector Mounting Brackets (ACW-724)
Warranty
1-Year Limited Warranty
SpeedFusion Features
Hot Failover, Smoothing, Bandwidth Bonding (license-dependent)
Router Throughput
1Gbps
Dimensions
6.3 x 3.8 x 1.3 inches / 160 x 97 x 33.5 mm
Wi-Fi Interface
Simultaneous Dual-Band (2.4GHz / 5GHz) Wi-Fi 6 2x2 MIMO; transmit power 21dBm (2.4GHz), 22dBm (5GHz); Multiple SSIDs: 16
AP Controller
30 / 50
Edge Computing
8GB Storage
Cellular Antenna Connectors
4x SMA Cellular Connectors
GPS Antenna Connector
Yes
Maximum Number of APs Supported
30 / 50 (controlled AP / Switch)
PepVPN Throughput (No Encryption)
400Mbps (SpeedFusion VPN, No Encryption)
PepVPN Throughput (256-bit AES)
200Mbps (SpeedFusion VPN, 256-bit AES)
Cellular 1 Data Rate (Downlink/Uplink)
CAT-12: 600 Mbps / 150 Mbps CAT-7: 300 Mbps / 150 Mbps
Number of PepVPN / SpeedFusion Peers
2 / 5 / 10 / 20
802.1q VLANs Supported
128
Drop-In Mode
Yes
High Availability
Yes
Number of IPsec Tunnels
5
PoE Output
No
Operating Temperature
-40°–149°F / -40°–65°C
Compatibility
US Carrier Certifications: AT&T, T-Mobile, Verizon, FirstNet
Features
Edge Computing with 8GB Storage, Ignition Sensing
Serial
Yes (RS-232)
Recommended PPTP/L2TP/OpenVPN Users
L2TP/PPTP/OpenVPN users: 3
