In stock · Ready to ship Peplink Antenna MAX Duo IP67 Router Enclosure with 8x8 MIMO, Wi-Fi and GPS
Antennas

Peplink Antenna MAX Duo IP67 Router Enclosure with 8x8 MIMO, Wi-Fi and GPS

$799.00per unit

IP67 enclosure with eight cellular, two Wi-Fi and GPS antennas for a BR2 Pro or two BR1 Pro or BR1 Mini 5G routers.

SKU: ANT-MAX-DUO
Quantity
Overview

Dual-modem routers and paired routers need eight cellular elements, and mounting them outdoors with external antennas gets unwieldy.

The Peplink Antenna MAX Duo houses a BR2 Pro, two BR1 Pro 5G or a BR1 Pro 5G and BR1 Mini 5G inside an IP67 UV-stable polycarbonate dome with eight cellular elements covering 617 to 6000 MHz at up to 8.1 dBi, two dual-band Wi-Fi elements at up to 7.4 dBi and an active GPS element. It measures 427.5 mm across and 122.5 mm tall, rated -40 to 80 °C, and mounts on a pole, surface or standard maritime VSAT dome mount.

Paired-router configurations require the Splitter MAX. The L-mount set, rubber supports, RJ45 glands and Ethernet cables ship in the box.

Product details
In the box
  • 1x Antenna MAX Duo
  • 1x L-Mount Set
  • Router Fixation Screws
  • 5x Rubber Support TNF-19
  • 3x Rubber Support TF-039
  • 3x RJ45 Glands
  • 2x RJ45 Caps
  • 1x Double-Sided 3M Adhesive Pad
  • 1x Ethernet Cable (250 mm)
  • 1x Ethernet Cable (380 mm)
Built for
Workboat and tug wheelhouse roofsOil field and pipeline camp sitesRooftop dual-carrier backupEmergency operations rooftop mastsRail yard tower mounts
Specifications
Enclosure
IP67; UV stable PC; UL 94 V-0 (1.47 mm)
Certifications
UL 94 V-0 (1.47 mm); UL 746C (F1 long-term UV exposure); MIL-STD 810F/ASTM B117; ROHS, REACH, WEEE; TAA Compliant
Package Content
L-Mount Set, Router fixation screws, 5pcs Rubber Support TNF-19, 3pcs Rubber Support TF-039, 3pcs RJ45 glands, 2pcs RJ45 caps, 1pcs Double sided 3M adhesive pad, 1pcs Ethernet cable (9.84" / 250mm), 1pcs Ethernet cable (14.96" / 380mm)
Warranty
1-Year Limited Warranty
Dimensions
4.82" / 122.5 mm - Height, 16.83" / 427.5 mm - Diameter; Package 21.97" x 25.51" x 16.46" / 558 x 648 x 418 mm
Cellular Antenna Connectors
Cellular: Right angle SMA male (8 elements); GPS: Right angle SMA male; Wi-Fi: Right angle RP-SMA male (2 elements)
GPS Antenna Connector
GPS 1575-1602 MHz; 0.9dBi@1575MHz, 0.8dBi@1602MHz; LNA Gain 27 ±3dB; Noise Figure 2.5dB; Operating Voltage 3.3V; Power Consumption 10 ±3.0mA
Operating Temperature
-40° - 176°F / -40° - 80°C (storage: -40° - 176°F / -40° - 80°C)
Compatibility
BR2 Pro; 2x BR1 Pro 5G (requires Splitter MAX); BR1 Mini 5G + BR1 Pro 5G (requires Splitter MAX)
Other
Integrated Dual-Modem or Dual-Router Antenna Housing. Mounting: Pole Mount (vertical or horizontal), Adhesive Surface Mount, Surface Mount; compatible with standard maritime VSAT dome mounts
Antenna Connectors
Cellular: 5.6dBi: 617–960MHz, 6.5dBi: 1410–2700MHz, 8.1dBi: 3400–4400MHz, 7.4dBi: 5000–6000MHz; 8 elements; VSWR < 2.5 over 95% of the band; 10W; 50 Ω; Linear. Wi-Fi: 5.4dBi: 2400–2500MHz, 7.4dBi: 5000–6000MHz; 2 elements; VSWR < 2.5; 10W; 50 Ω; Linear
