In stock · Ready to ship Peplink SD Switch 24-Port 2.5G PoE+
PoE Switches

Peplink SD Switch 24-Port 2.5G PoE+

$799.00per unit

24-port PoE+ switch with sixteen gigabit and eight 2.5G ports, four 10G SFP+ uplinks and a 410W budget, managed from InControl.

SKU: PLS-24-H2G-410W
Additional Warranty*
Plan
Quantity
Overview

A branch closet needs powered ports for phones, cameras and access points, with a few faster ports for the newer Wi-Fi.

The Peplink SD Switch 24-Port provides sixteen gigabit and eight 2.5G RJ45 ports, all with 802.3at PoE+, plus four 10G SFP+ uplinks, on a 410W PoE budget with 152 Gbps of switching capacity. It runs on 100 to 240V AC with a 480W internal supply, rated 0 to 50 °C, at 4.1 kg.

InControl 2 manages it alongside the routers, and PrimeCare A plans cover it. Mounting brackets, power cord, screws and feet ship in the box.

Product details
In the box
  • 1x Switch
  • 1x Power Cord
  • 1x Screw Set
  • 1x Rubber Foot Pad Set
  • 1 Pair of Mounting Brackets
Built for
Branch office wiring closetsClinic and dental office networksCharter school classroomsRetail store back officesSmall municipal buildings
Specifications
LAN Interface
16x 1GE l 802.3at PoE+ RJ45 ports; 8x 2.5GE l 802.3at PoE+ RJ45 ports; 4x 10G SFP+ ports
Power Input
1x 100V – 240V AC
Power Consumption
38W (System)
Weight
9.0 pounds / 4.1 kg
Humidity
15% – 95% (non-condensing)
Certifications
FCC, CE, RoHS
Package Content
1x 24 PoE 2.5G Switch | 1x Power Cord | 1x Screw Set | 1x Rubber Foot Pad Set | 1 Pair of Mounting Brackets
Warranty
1-Year Limited Warranty
Router Throughput
Switching Capacity 152 Gbps; Forwarding Rate 216 Mpps; MAC Address Table 16,000
Dimensions
10.3 x 17.3 x 1.8 inches / 260 x 440 x 45 mm
PoE Output
802.3at PoE+; Total PoE Power Budget 410W
Operating Temperature
32° – 122°F / 0° – 50°C
Serial
Console Port
